Cisco 3945 K9 ISR 3-Port GbE Enterprise Router 4x EHWIC Security | Wty
Cisco 3945 ISR — High-Performance Modular Integrated Services Router
The Cisco 3945 Integrated Services Router (ISR G2) is a 2U modular enterprise router featuring 3 × 10/100/1000 GbE WAN ports, 4 × eHWIC slots, 4 × Service Module slots, hardware IPsec VPN, and a high-performance multicore CPU. This unit ships with a C3900-SPE150/K9 Services Performance Engine, 2 × VIC2-2BRI voice interface cards, a VWIC3-1MFT-T1/E1 voice/WAN card, and an SM-D-ES3G-48-P 48-port GbE switch module installed. Backed by a full 12-month Reboot IT warranty. Note: No flash card or Cisco IOS image is included.
Key Benefits
- 4 Service Module slots: Double the capacity of the 2951 — install high-density WAN, voice, security, and switching modules simultaneously for complex multi-service branch deployments
- SPE-150 performance engine: The included C3900-SPE150/K9 offloads crypto and processing, enabling higher VPN and routing throughput than base-model ISR G2 platforms
- Hardware IPsec VPN: Dedicated AES/3DES encryption accelerator handles site-to-site and remote-access VPN tunnels without impacting route processor performance
- Included voice modules: Ships with 2 × VIC2-2BRI-NT/TE and 1 × VWIC3-1MFT-T1/E1 — ready for ISDN BRI and T1/E1 voice gateway deployment out of the box
- 48-port GbE switch module: The SM-D-ES3G-48-P provides 48 Gigabit Ethernet switching ports in a single service module slot, eliminating a separate access switch at smaller sites
- 1 GB DRAM: Higher memory capacity supports larger routing tables, more concurrent VPN tunnels, and memory-intensive IOS feature sets
Performance in Use
The Cisco 3945 aggregates multiple WAN connections (MPLS, Metro Ethernet, broadband), terminates IPsec VPN tunnels, and enforces security policies — all in a single chassis. The SPE-150 engine significantly increases throughput headroom over entry-level ISR G2 configurations, making the 3945 a strong choice for medium-to-large branch offices and multi-service hub sites.
The included SM-D-ES3G-48-P 48-port GbE switch module turns the 3945 into a combined router-plus-switch platform. This reduces rack space and cable complexity at branch sites where a dedicated access switch would otherwise be required, while the multigigabit fabric (MGF) ensures efficient communication between service modules and the route processor.
For unified communications deployments, the installed VIC2-2BRI and VWIC3-1MFT-T1/E1 cards enable PSTN gateway configuration for SIP or H.323 trunks alongside data routing on the same chassis. Network engineers studying for CCIE Enterprise or Voice can use the 3945 as a realistic multi-service lab platform covering routing, VPN, voice gateway, and switching scenarios simultaneously.
Technical Specifications
| GbE WAN Ports | 3 × 10/100/1000 (1 SFP-capable dual-purpose) |
| eHWIC Slots | 4 × eHWIC (WAN, switching, voice, and wireless cards) |
| Service Module Slots | 4 × Service Module slots |
| ISM Slot | 1 × Internal Services Module slot |
| Memory | 256 MB NAND Flash / 1 GB DRAM |
| Encryption | Hardware IPsec (AES, 3DES) via onboard accelerator |
| Included Modules | C3900-SPE150/K9, 2 × VIC2-2BRI-NT/TE, VWIC3-1MFT-T1/E1, SM-D-ES3G-48-P |
| USB Ports | 2 × USB 2.0 (console + flash storage) |
| Form Factor | 2U rack-mount, 483 mm (W) × 457 mm (D) |
| OS / Flash | Not included — flash card and Cisco IOS must be purchased separately |
| Warranty | 12 months (Reboot IT) |
Is It Right for You?
| Best For ✓ | Not For ✗ |
|---|---|
| Medium-to-large branch WAN aggregation and VPN | Plug-and-play deployments (requires IOS + config) |
| Multi-service voice, security, and switching in one chassis | SD-WAN or cloud-managed deployments |
| CCIE Enterprise and voice lab environments | Simple home or SOHO routing needs |
| ISDN BRI / T1/E1 voice gateway integration | High-throughput internet edge routing |
Condition Grades
| Grade | Description |
|---|---|
| A — Excellent | Minimal signs of rack use. Light scuffs or micro-scratches only. All ports, slots, and interfaces fully tested and functional. |
| B — Good | Visible chassis wear — scratches, scuff marks, or minor paint chips. Fully functional. All components tested and verified. |
Frequently Asked Questions
Does this come with a flash card or Cisco IOS?
No — this unit ships without a flash memory card and without Cisco IOS software. You will need to purchase a compatible CompactFlash card and obtain a Cisco IOS licence separately before the router can operate.
What modules are included with this unit?
This unit includes: C3900-SPE150/K9 (Services Performance Engine 150), 2 × VIC2-2BRI-NT/TE (ISDN BRI voice interface cards), 1 × VWIC3-1MFT-T1/E1 (T1/E1 voice/WAN card), and 1 × SM-D-ES3G-48-P (48-port Gigabit EtherSwitch module). Module configuration may vary by unit.
How does the 3945 differ from the 2951?
The 3945 has 4 Service Module slots (vs 2 on the 2951), 1 GB DRAM (vs 512 MB), and higher overall throughput capacity. It is suited to medium-to-large branches with higher concurrent service demands across routing, security, voice, and switching.
Is this suitable for CCNP or CCIE lab use?
Yes — the 3945 is an excellent lab platform for CCNP Enterprise and CCIE Enterprise or Voice study. The included voice and switch modules extend lab scenarios to cover unified communications, multi-tier LAN design, and T1/E1 WAN simulation.
What warranty is included?
A 12-month Reboot IT warranty covers all hardware components from the date of purchase.
How does shipping work?
Shipping costs apply based on size and destination — rates are calculated at checkout.
12-Month Warranty — Reboot IT
Every Cisco 3945 ISR sold by Reboot IT includes a full 12-month warranty covering all hardware components. Reboot IT has been Melbourne’s trusted refurbished IT specialist since 2001, operating from reboot-it.com.au. Note: flash card and Cisco IOS are not included with this unit.
